SFQY series single head full pneumatic liquid filling machine (explosion-proof)

■ Filling liquids and viscous liquids such as food, pharmaceuticals, cosmetics, oils, and daily chemicals; ■ Suitable for filling liquids in various specifications such as round bottles, square bottles, and special-shaped bottles.

Send Inquiry

Send Email

Description

Technical parameter

Products Description

Brand: SFXB
Commodity name: SFQY series single head full pneumatic liquid filling machine (explosion-proof)

SFQY series single head full pneumatic liquid filling machine (explosion-proof)

Technical parameter

the project	SFQY-60	SFQY-120	SFQY-250	SFQY-500	SFQY-1000	SFQY-2000	SFQY-5000	SFQY-10000
Filling range	5~60ml	10~120ml	25~250ml	50~500ml	100~1000ml	200~2000ml	500~5000ml	1000~10000ml
Ideal filling range	25~60ml	50~120ml	100~250ml	200~500ml	400~1000ml	800~2000ml	2000~5000ml	500~10000ml
air supply	0.4~0.6Mpa
Filling speed	0~35 bottles/min	0~30 bottles/min			0~25 bottles/min BPM	0~20 bottles/min	0~15 bottles/min	0~10 bottles/min
Filling accuracy	±≤1 liquid (with water as the standard, the accuracy can be achieved by more than 30% of the maximum filling value )
weight	14kg	15kg	20kg	20.5kg	26 kg	35kg	53kg
Host size ( mm )	805×442×515

Scope Of Application

■ Full pneumatic control, explosion-proof function, easy operation, 304 stainless steel appearance;

■ The material contact parts are all made of 316 L stainless steel, which is corrosion-resistant, and the key parts are precisely processed;

■ High filling accuracy, it is an ideal equipment for filling liquids and liquids with a certain viscosity;

■ Easy to disassemble and clean, both automatic and manual.

■ Filling liquids and viscous liquids such as food, pharmaceuticals, cosmetics, oils, and daily chemicals;
■ Suitable for filling liquids in various specifications such as round bottles, square bottles, and special-shaped bottles.
